The Q-2B (part number B86667) is the 75HP slasher gearbox with an integral output hub, eliminating the need for a separate stub shaft coupler between the gearbox and the blade disc. This is the integral hub variant in the 75HP range, sitting alongside the Q-2 (1:1.47 ratio) and Q-2A (1:1.93 ratio) which use a conventional output shaft arrangement. Freight is paid to any destination in Australia.

Specifications

• Model: Q-2B, Part number: B86667
• HP rating: 75HP
• Gear ratio: 1:1.93
• Input shaft: 1-3/8" 6 spline (standard PTO, suits all common drive shafts)
• Integral output hub eliminates separate shaft coupler
• Weight: 34.5kg

When the Q-2B Is the Right Choice

The integral hub design is specified on slasher platforms that are engineered to mount the blade disc directly onto the gearbox output hub rather than through a separate stub shaft arrangement. If your existing gearbox used a separate coupler, the Q-2A B6667 is the likely replacement. If your machine had an integral hub style from the factory, the Q-2B is the correct fit.

A specification sheet PDF is available on request. Add EP140 gear oil before first use. Spare parts available on application. Complete transmission kits for the 75HP range are available in the Q8-9980 Series.
