Reduced to clear V Band Clamp W2 VT10525 (5.25")
Turbo V Band Clamps are used in applications where two flanged joints have to be coupled together.V Band clamps are used to connect a vehicle exhaust pipe flange to the turbo or engine manifold.
V Band Clamps can withstand high temperatures produced by heavy duty engines and turbos.These clamps are manufactured to the highest tolerances and meet or exceed most O.E.M. specifications.V Band clamps are made from stainless steel with a zinc plated bolt.A detailed brochure is available.
No minimum quantity to order.
This V Band clamp is a direct replacement for the following OEM Part numbers
CAT 8N2745 DDC 5132650,513262 GM 2011586 VOLVO 02-7105902
R.G.Ray 10134 DD 8V71T,16V-71,16V-92T,6V92,8V92 AIRSEARCH T1899
FREIGHTLINER 01-14551 NAVISTAR 9300 SERIES WDD8V71,8V92,780067C91
AP 9616,DONALDSON P210110, DYNAFLEX 41-450S,EX AIR 88-456,GRAND ROCK VB-5250 HEAVY DUTY 21-125,NELSON 89510K,STEMCO 250-1017,WALKER 35746
VT10525 CROSS SECTION DIAGRAM A = .050 B = .262 C = .141 D = .035 E = .750
